MORryde TV40-001H Tall Slide Out Base TV Mount - 50 lb. capacity -
Slide Out Base TV Mount
This adjustable slide out base TV mount fits perfectly in a cabinet, on a counter, desk, or any horizontal surface in your RV. This mount is excellent for under the cabinet installation or reinforced ceilings. The versatile design lets you slide out the TV, adjust the height and swivel and tilt into place. A locking mechanism keeps your TV or monitor secure in the out position or locked in for travel.
- Slides out 7"
- Swivels up to 30°
- Tilts 0-10.5°
- Up to 55" TV
- Locks into tilt position
- Locking mechanism
- 50 lb. weight capacity
- VESA mounting patterns
- TV mounting base
- TV mounting hardware
- Installation hardware
- Installation instructions
.
Angle your TV to the perfect viewing position with this adjustable base mount in your RV. The versatile design lets you slide out, swivel, and tilt your TV or monitor where you want it. With a unique locking system, your TV will stay secure whether it’s out from the base for watching or tucked in for travel.
EASILY CHANGE HEIGHT of TV with adjustable mount
GET A CLOSE-UP VIEW with 7″ slide out
ANGLE YOUR TV with a ±30º swivel range
KEEP TV SECURE with sturdy locking mechanism
MOUNT EASILY with VESA mounting patterns up to 200mm x 200mm*
DIMENSIONS
- Overall : 17″H x 9.25″W x 14.5″D
- Base mounting plate dimensions : 6″W x 8″D
- VESA adapter plate : 9.375″H x 9.25″W
VESA MOUNTING PATTERNS
- 75×75
- 100×100
- 200×200*
Catalog Technical Specs
- Part Number: TV40-001H
- Mount Type: Slide Out base mount, tall configuration
- Dimensions: 6" W x 17" H x 15.8" D
- Capacity: 50 lbs
- Max TV Size: Up to 55" TV
- Slide Travel: Slides out 7"
- Motion: Swivels and tilts 0-10.5°
- Adjustment: Adjusts for TV height
- VESA: Up to 200 x 200
- Base Plate Orientation: Faces toward the front
