Dometic 5 Amp Circuit Breaker - Furnace Overload Protection - Part# 30320
The Dometic 5 Amp Circuit Breaker (Part# 30320) provides critical overload protection for Dometic RV furnaces, preventing electrical damage from power surges and short circuits. This automatic reset breaker is designed to trip when current exceeds 5 amps, protecting your furnace's control board and motor components. Essential for maintaining safe furnace operation and preventing costly repairs.
Key Features
- 5 Amp Rating: Precisely calibrated to protect furnace electrical components from overload conditions
- Automatic Reset Design: Trips during overload and can be manually reset without replacement
- OEM Replacement: Direct factory replacement for worn or failed circuit breakers in Dometic furnaces
- Compact Mounting: Designed for easy installation in tight furnace compartments
- Temperature Rated: Built to withstand the heat environment inside RV furnace enclosures
- Quick Diagnosis: Visible trip indicator helps identify electrical issues quickly
Technical Specifications
| Part Number | 30320 |
| Amperage Rating | 5 Amp |
| Voltage | 12V DC |
| Breaker Type | Automatic Reset, Push-to-Reset |
| Application | RV Furnace Protection |
| Mounting Style | Panel Mount |
Compatible Dometic Furnace Models
This circuit breaker is used in various Dometic furnace models. Verify your furnace's part number or consult your owner's manual to confirm compatibility.
Frequently Asked Questions
How do I know if my furnace circuit breaker needs replacement?
Signs include: furnace won't start, breaker trips repeatedly even after reset, breaker won't stay reset, or visible damage to the breaker housing. If your breaker trips frequently, investigate the underlying electrical issue before replacing.
Can I use a standard automotive circuit breaker instead?
No. This Dometic breaker is specifically designed for RV furnace applications with precise amperage ratings and temperature tolerances. Using incorrect breakers can result in inadequate protection or nuisance tripping.
What causes a furnace circuit breaker to trip?
Common causes include: motor bearing failure drawing excessive current, shorted wiring, control board issues, or blower wheel obstruction. If the breaker trips immediately after reset, there's likely a short circuit that needs repair.
How do I reset this circuit breaker?
Locate the breaker (usually near the furnace control board), press the reset button firmly until it clicks. If it trips again immediately, disconnect power and investigate for electrical faults before attempting further resets.
Why Choose Elkhart RV Parts?
We specialize in hard-to-find Dometic RV parts that keep your systems running reliably. Located in Elkhart, Indiana — the RV Capital of the World — we understand the urgency of getting your RV back in service. We stock genuine OEM Dometic parts and ship fast across the United States. Our team knows Dometic systems inside and out, so if you have questions about compatibility or installation, we're here to help.
