Dometic 8500 Manual Awning - 12' Polar White - 8' Projection - Model 848CQ12.40TB
The Dometic 8500 Manual Awning delivers proven performance and durability for straight-wall RV applications. This 12-foot polar white awning features double-sided vinyl fabric with integrated WeatherShield protection, manual crank operation with auto-tensioning, and self-locking ratcheting arms for secure, one-person deployment in minutes.
Key Features
- 12-Foot Coverage: Nominal 12-foot fabric (actual 11'3.38") with 8-foot projection provides generous shade and weather protection
- Double-Sided Polar White Vinyl: Durable vinyl fabric with matching Polar White WeatherShield for superior UV and weather resistance
- Manual Crank with Auto-Tensioning: Smooth manual operation with automatic fabric tensioning eliminates sagging and ensures proper deployment every time
- Self-Locking Ratcheting Arms: Torsion arms lock securely at any position for reliable stability and wind resistance
- One-Person Operation: Engineered for easy solo deployment and retraction with integrated PermaLoop pull strap and wind-lock system
- Wall-Mount Design: Purpose-built for straight RV sidewalls with proven mounting reliability
- Lightweight Construction: Weighs approximately 47.7 pounds for manageable installation and reduced vehicle load
- OEM Quality: Genuine Dometic engineering with field-proven components and comprehensive replacement parts availability
Specifications
| Model Number | 848CQ12.40TB |
| SKU | 9600007332 |
| PNC | 958690108 |
| Nominal Fabric Length | 12 feet |
| Actual Fabric Length | 11'3.38" |
| Projection | 8 feet |
| Fabric Type | Double-Sided Vinyl |
| Fabric Color | Polar White |
| WeatherShield Color | Polar White |
| End Cap Color | Polar White |
| Operation Type | Manual Crank with Auto-Tensioning |
| Arm Type | Self-Locking Ratcheting Torsion Arms |
| Mounting Style | Wall-Mount for Straight RVs |
| Weight | Approximately 47.7 lbs |
| Pull Strap | PermaLoop Design |
| Wind Protection | Wind-Lock System |
What's Included
- Aluminum Roller Tube with Torsion Assembly
- 12' Polar White Double-Sided Vinyl Fabric (actual 11'3.38")
- Polar White WeatherShield
- PermaLoop Pull Strap
- Wind-Lock Hardware
- Mounting Hardware
Sold Separately - Required for Installation
Torsion Arms: Left-hand and right-hand torsion arm assemblies are sold separately and required for complete installation.
Pole Kit or Rail Kit: A 1-pull pole kit, 2-pull pole kit, or rail kit (items 130280-130283) is required for proper operation and must be purchased separately.
Installation Requirements
- Mounting Surface: Straight RV sidewall with adequate structural support
- Required Components (Sold Separately): Left-hand torsion arm assembly, right-hand torsion arm assembly, and either a 1-pull pole kit, 2-pull pole kit, or rail kit (items 130280-130283)
- Tools Needed: Standard hand tools, drill, appropriate drill bits, measuring tape, level, and ladder
- Installation Time: Approximately 2-4 hours for experienced installers
- Clearance: Ensure adequate clearance above and below mounting area for full awning extension and retraction
- Professional Installation: Recommended for proper mounting, alignment, and warranty compliance
Keep Your 8500 Running — Genuine OEM Replacement Parts
Maintain peak performance with authentic Dometic replacement components engineered specifically for the 8500 awning system. Every part is precision-manufactured to exact OEM specifications for perfect fit and lasting durability.
| Part | Description | Part Number |
|---|---|---|
| #520 | 90.50" PermaLoop Pull Strap | 3108708.359 (superseded by 9108677537) |
| #521 | Right-Hand Torsion Arm Assembly 8500/9000, Polar White | 3108399.035B |
| #522 | Left-Hand Torsion Arm Assembly Kit 8500/9000, Polar White | 3108399.019B |
| #523 | 12' Replacement Aluminum Roller Tube | 3108346.012 |
| #524 | 12' Polar White Vinyl Fabric with WeatherShield (actual 11'3.38") | B3314989CQ.412 |
Why Elkhart RV Parts?
As a trusted Dometic authorized dealer, Elkhart RV Parts delivers the authentic components and expertise you need to keep your RV awning system operating flawlessly. We stock genuine OEM parts, provide accurate technical specifications, and back every order with knowledgeable support from our team of RV specialists. Whether you're installing a new awning or maintaining your existing system, we ensure you receive the right parts with fast shipping and the confidence that comes from decades of RV industry experience.
